Inspire Series 343

The Inspire Series 343 has a total of 233 voices spread of 43 illuminated stop tabs, a variant library and 18 orchestral selections. Equipped with three velocity-sensitive manuals, a 32-note ago pedal board and an internal 2.1 audio system with the option of expanding to a 6.2 plus 2-channel antiphonal external audio system, the Inspire Series 343 is a state-of-the-art church and concert organ with unending flexibility.

  • 43 stops / 233 total voices
  • 4 unique organ styles + Variant Library
  • 215 Voice Palette™ voices
  • 18 orchestral voices
  • 50 Memory Levels x 10 general pistons & 20 divisionals
Request A Quote
  • Traditional wood veneer cabinet with deluxe wood tambour
  • Available in light, medium and dark oak veneer
  • Matching wood veneer back panel
  • LED lighted music desk
  • Tab stop controls
  • Record/playback with STOP, PLAY, REC pistons
  • USB-enabled for unlimited storage of registration data and saved performances
  • Hymn Player automatically plays 350 built-in hymns with introduction & verse or Prelude mode
  • Bench in matching finish
  • Hardwood rolltop + lock
  • 32-note radiating AGO pedalboard velocity-sensitive for orchestral voices
  • Self-contained pedalboard mechanism for greater reliability on uneven flooring or carpeting
  • Kick switch programmable as Off, Next, Prev, Sustain and Gospel Rotor for orchestral voices
  • Programmable pedal F# sustain function for orchestral voices
  • Memory +/- pistons
  • 9 historic temperaments
  • True Sound Space: 12 real reverb environments
  • 2.1-channel internal audio system: 2 channels x 50 watts fullrange audio + 1 channel x 160 watts subwoofer
  • MIDI In and Out connections
  • Stereo headphone jack
  • 2 x ¼” Stereo Line inputs
  • 2 x ¼” Stereo Line outputs
  • Tuning control
  • -6/+5 transposer (resets to 0 with general cancel piston)
  • 5 loudspeakers using coaxials for a rich and highly defined sound
  • 8-channel external audio outputs
  • 2-channel audio system for external loudspeakers (optional)
  • Internal Audio OFF, Main OFF, Antiphonal ON
  • Onboard voicing finishing and leveling controls
  • Pipe organ modeling technologies
  • Great/Pedal Enclosed
  • Organ Type piston instantly activates American Eclectic, English Cathedral, French Romantic or German Baroque stops
  • Adjustable tremulants

Model 343 Inspire Series Specifications

AMERICAN ECLECTIC ENGLISH CATHEDRAL FRENCH ROMANTIC GERMAN BAROQUE VARIANT LIBRARY

GREAT

Violone 16 Open Diapason 16 Bordun 16 Montre 16 Quintaton 16
Principal 8 Open Diapason 8 Montre 8 Prinzipal 8 Diapason 8
Bourdon 8 Chimney Flute 8 Bourdon 8 Rohrflöte 8 Clarabel Flute 8
Gamba 8 Second Diapason 8 Flûte Harmonique 8 Quintatön 8 Doppel Flute 8
Erzähler Céleste II 8 Salicional 8 Gambe 8 Salicional 8 Voix des Anges II 8
Octave 4 Principal 4 Prestant 4 Oktave 4 Harmonic Flute 4
Spitzflöte 4 Waldflute 4 Flute Ouverte 4 Gemshorn 4 Quint 2-2/3
Super Octave 2 Fifteenth 2 Doublette 2 Super Oktave 2 Harmonic Piccolo 2
Cornet V Cornet IV Cornet IV Kornett V Terz 1-3/5
Fourniture IV Mixture IV Fourniture IV Mixtur VI Cymbel III
Trumpet 8 Tromba 8 Trompette 8 Trompete 8 French Horn 8
Great Orch A
Great Orch B
Tremulant
Swell to Great
Choir to Great

CHOIR
Principal 8 Diapason 8 Montre 8 Spitz Prinzipal 8 Bach Principal 8
Gedackt 8 Concert Flute Bourdon 8 Gedackt 8 Gross Flute 8
Unda Maris II 8 Gemshorn Celeste II 8 Viola Celeste II 8 Spitzgamba 8 Viola Pomposa 8
Octave 4 Principal 4 Prestant 4 Oktave 4 Musette 4
Koppelflöte 4 Orchestral Flute 4 Nachthorn 4 Blockflöte 4 Unda Maris II 4
Spitzflöte 2 Nachthorn 2 Piccolo 2 Gemshorn 2 Doublette 2
Larigot 1-1/3 Nineteenth 1-1/3 Quinte 1-1/3 Sifflöte 1 Sept-Terz II
Scharff III Mixture III Cymbel III Mixtur III Sesquialter II
Festival Trumpet 8 Royal Tuba 8 Trompette en Chamade 8 Schalmey 8 Corno di Bassetto 16
Choir Orch A
Choir Orch B
Swell to Choir
Tremulant

SWELL
Bourdon Doux 16 Bourdon 16 Dulciane 16 Lieblich Gedackt 16 Violon 16
Diapason 8 Horn Diapason 8 Montre 8 Prinzipal 8 Geigen Principal 8
Bourdon 8 Stopped Diapason 8 Bourdon 8 Holzgedackt 8 Harmonic Flute 8
Viole Céleste II 8 Viola Céleste II 8 Voix Céleste II 8 Gamba 8 Flute Céleste II 8
Octave 4 Octave Gamba 4 Prestant 4 Oktave 4 Fugara 4
Flute Traverse 4 Flute 4 Flûte Octaviante 4 Flöte 4 Rohrflute 4
Nazard 2-2/3 Quintflute 2-2/3 Nazard 2-2/3 Nasard 3 Sesquialtera II
Block Flute 2 Lieblich Piccolo 2 Octavin 2 Waldflöte 2 Italian Principal 2
Tierce 1-3/5 Seventeenth 1-3/5 Tierce 1-3/5 Quinte 1-1/3 Sifflöte 1
Plein Jeu IV Mixture III Plein Jeu III Scharff IV Ripieno IV
Double Trumpet 16 Trombone 16 Bombarde 16 Posaune 16 Basson 16
Trumpet 8 Trumpet 8 Trompette 8 Trompete 8 Basson 8
Oboe 8 Cornopean 8 Hautbois 8 Dulzian 8 Vox Humana 8
Swell Orch A
Swell Orch B
Tremulant

PEDAL
Contra Bourdon 32 Dbl. Open Diapason 32 Contra Violon 32 Untersatz 32 Open Wood 32
Principal 16 Open Diapason 16 Contrebasse 16 Prinzipalbass 16 Violone 16
Subbass 16 Bourdon 16 Soubasse 16 Bordun 16 Bourdon Doux 16
Octave 8 Diapason 8 Montre 8 Oktave 8 Violoncello 8
Bass Flute 8 Flute 8 Bourdon 8 Gedackt Bass 8 Lieblich Bourdon 8
Choral Bass 4 Fifteenth 4 Prestant 4 Oktave 4 Nachthorn 4
Mixture III Mixture III Plein Jeu III Hintersatz II Clairon 4
Bombarde 16 Trombone 16 Bombarde 16 Posaune 16 Bass Clarinet 16
Trumpet 8 Tromba 8 Trompette 8 Trompete 8 Trombone 8
Pedal Orch A
Pedal Orch B
Great to Pedal
Swell to Pedal
Choir to Pedal

INSPIRE 343 CONSOLE DIMENSIONS

Height: 49” (124.5 cm)

Width: 60.0” (152.4 cm)

Depth: 29.9” (75.9 cm)

Depth with pedalboard: 46.5” (118.1 cm)
